Concaver CVR1 22x10" (5 trous - sur mesure) ET20-64, Titane

Concaver 4.9/5 from 343 customer reviews

Concaver CVR1 22x10" (5 holes - custom) ET20-64, Titanium

Ref. CVR12210P5X2074BT

799,99 € incl. VAT

Secure payment
14-day returns
Technical support

🔒 Secure payment 🚚 Tracked shipping across Europe ↩️ 14-day returns 🛠️ Technical support⭐ Rated 4.9/5 by our customers🏁 Enthusiasts since 2017

Concaver

CVR1 22×10" — Titanium

5 holes, 108 to 130 mm selectable · ET 20 to 64 · Machined to order

Sold individually Custom-made TÜV approved Hybrid forged Hardware included

The Concaver CVR1

Five slim double spokes and pronounced concavity: the CVR1 is Concaver's foundational design, the wheel that established the brand in the supercar-inspired concave wheel segment.

Technical specifications

Diameter

22 inches

Width

10 inches

Center bore

74.1 mm

Color

Titanium

Bolt pattern

5 holes108 to 130 mm

Offset (ET)

ET 20 to 64

Max. load

980 kg / wheel

74.1 mm center bore: if your vehicle's hub is smaller, a centering ring fills the gap and ensures the wheel is correctly centered. Rings are supplied according to the vehicle you provide.

TÜV approval: this model is certified by the German organization, the most demanding reference on the European market. The report lists the covered vehicles and, where applicable, the installation conditions. Ask us for the report corresponding to your vehicle if needed.

Wheel machined to order

Specify your vehicle when ordering

This Concaver is not machined in advance: its bolt pattern (5 holes, from 108 to 130 mm) and its offset (ET 20 to 64) are made to your specifications. Enter your exact vehicle model in the form above — without this information, the wheel cannot be manufactured. Not sure? Write to us before ordering; we will determine the correct specifications together.

Specific offset: the wheel is supplied in ET 20 by default. If you want another value within the range, indicate it in the form: machining to this specification costs €20 per wheel, automatically added to the cart.

You place your order

Choose the diameter, width and color, then enter your vehicle and, if needed, the desired offset (+€20 per wheel).

We confirm the specifications

We check the bolt pattern, offset and clearance on your vehicle before starting production.

The wheel is machined

Allow approximately one additional week for machining or custom paint.

Shipping

Delivery includes the hardware, centering rings and matching center cap.

What's included

Concaver CVR1 22×10" wheel (sold individually)
Hardware suitable for your vehicle — included
Centering rings suitable for your vehicle — free with any order of 4 wheels
Matching Concaver center cap — always included, regardless of quantity
TÜV approval
Bolt pattern and offset machined to your specifications
Maximum permissible load: 980 kg per wheel

Construction: hybrid forged

Concaver uses Flow Forming, also known as flow forging: the wheel is stretched while hot as it rotates, densifying the material around the tire bead seat. The result sits between a conventional cast wheel and a fully forged wheel — significantly stiffer and lighter than the former, without reaching the cost of the latter.

This process allows Concaver to offer deeply concave designs in large diameters at an accessible price.

Why Concaver

Machined to your specifications

Custom bolt pattern and offset: the wheel adapts to your vehicle, not the other way around.

TÜV approved

The most demanding European certification, rare in this price segment.

Pre-purchase advice

Bolt pattern, offset, clearance, camber: we confirm the fitment with you before machining begins.

Installation and hardware

Unlike most brands, the suitable hardware is included with your Concaver wheels, along with the centering rings and center cap. Simply specify your vehicle when ordering.

Need additional hardware or specific parts? See our lug nut packs and wheel bolt packs, or ask us for advice.
